ncs_cli -u admin
admin@ncs# config
admin@ncs(config)# services l3vpn my-first-l3vpn
admin@ncs(config-l3vpn)# vrf-rd 65000:1000
admin@ncs(config-l3vpn)# vrf-rt-export 65000:1000
admin@ncs(config-l3vpn)# vrf-rt-import 65000:1000
# ----- PE Site sample7 (PE1) Configuration -----
admin@ncs(config-l3vpn)# pe-site sample7
admin@ncs(config-l3vpn-pe-site)# pe-loopback-ip 10.10.10.10
admin@ncs(config-l3vpn-pe-site)# pe-as-number 65000
admin@ncs(config-l3vpn-pe-site)# core-interface-name GigabitEthernet0/0/0/0
admin@ncs(config-l3vpn-pe-site)# ce-connection
admin@ncs(config-l3vpn-pe-site-ce-connection)# interface-name GigabitEthernet0/0/0/1
admin@ncs(config-l3vpn-pe-site-ce-connection)# interface-ip 192.168.1.10
admin@ncs(config-l3vpn-pe-site-ce-connection)# interface-mask 255.255.255.0
admin@ncs(config-l3vpn-pe-site-ce-connection)# ce-interface-ip 192.168.1.11
admin@ncs(config-l3vpn-pe-site-ce-connection)# ce-as-number 65001
admin@ncs(config-l3vpn-pe-site-ce-connection)# exit
admin@ncs(config-l3vpn-pe-site)# exit
# ----- PE Site sampl9 (PE2) Configuration -----
admin@ncs(config-l3vpn)# pe-site sampl9
admin@ncs(config-l3vpn-pe-site)# pe-loopback-ip 30.30.30.30
admin@ncs(config-l3vpn-pe-site)# pe-as-number 65000
admin@ncs(config-l3vpn-pe-site)# core-interface-name GigabitEthernet0/0/0/0
admin@ncs(config-l3vpn-pe-site)# ce-connection
admin@ncs(config-l3vpn-pe-site-ce-connection)# interface-name GigabitEthernet0/0/0/1
admin@ncs(config-l3vpn-pe-site-ce-connection)# interface-ip 192.168.2.30
admin@ncs(config-l3vpn-pe-site-ce-connection)# interface-mask 255.255.255.0
admin@ncs(config-l3vpn-pe-site-ce-connection)# ce-interface-ip 192.168.2.31
admin@ncs(config-l3vpn-pe-site-ce-connection)# ce-as-number 65002
admin@ncs(config-l3vpn-pe-site-ce-connection)# exit
admin@ncs(config-l3vpn-pe-site)# exit
admin@ncs(config-l3vpn)# remote-pe-ip 10.10.10.10
admin@ncs(config-l3vpn-remote-pe-ip)# exit
admin@ncs(config-l3vpn)# remote-pe-ip 30.30.30.30
admin@ncs(config-l3vpn-remote-pe-ip)# exit
admin@ncs(config-l3vpn)# commit dry-run
